Nelson F150 Big Gun Sprinkler, 24° Full Circle, Flanged (9455-024)

The Nelson F150 9455-024 is a high-volume, full-circle Big Gun irrigation sprinkler with a 24-degree trajectory and flanged connection. It is built for large agricultural irrigation areas that need long-range rotating coverage, including center pivots, traveler systems, and solid-set installations.

Why choose the F150?

The 24-degree trajectory can help maximize throw distance when site and wind conditions allow. The flanged connection provides a secure mounting option for systems designed around flanged equipment.

Performance and Specifications:

• Model: 9455-024
• Brand: Nelson
• Series: F150
• Trajectory: 24 Degrees
• Pattern: Full circle
• Connection: Flanged
• Flow Rate: 90-630 GPM (20-143 m³/hr)
• Pressure: 50-120 PSI (3.5-8.25 bar)
• Applications: Center pivots, traveler systems, solid-set irrigation, and large agricultural fields

Nozzle is not included. Order the correct nozzle separately for your sprinkler, pressure, flow, and coverage requirements.

Also available: Nelson SR150 part-circle configurations.

Read the Nelson Big Gun sprinkler buying guide before comparing series, trajectory angles, connections, and nozzle options.
